ROBE-CLUBSPOT 500CT

"/>
Image Header
THIẾT KẾ CUNG CẤP THIẾT BỊ LẮP ĐẶT : RẠP HÁT, CHIẾU PHIM – VŨ TRƯỜNG – BAR, KARAOKE – KHÁCH SẠN – HỘI THẢO ĐA NGÔN NGỮ- CÁC GIẢI PHÁP VỀ CÔNG NGHỆ THÔNG TIN VIỄN THÔNG.

ROBE-CLUBSPOT 500CT

ROBE-CLUBSPOT 500CT
Giá bán: Liên hệ

ROBE-CLUBSPOT 500CT

Để biết thêm thông tin chi tiết về sản phẩm
Vui lòng liên hệ cho chúng tôi theo địa chỉ:
Email: phamhung@hdchanoi.com hoặc gọi điện
CSKH của HDC sẽ giúp bạn.
Tel: 0903445356 - - Tel/fax: 04. 3978 08 02
  • Thông tin sản phẩm
  • Thông số kỹ thuật



THÔNG SỐ ROBE-CLUBSPOT 500CT

Source

  • Lamp: Compact high-pressure metal halide lamp
  • Base: GX9.5
  • Approved models: Philips MSR 575/2, Osram HSR 575/72
  • Control: Automatic and remote on/off
  • Ballast: Magnetic

Optical System

  • Manual zoom 15° or 22°

Electrical Specification

    • Wiring options: EU-model - 208/230/240 V, 50/60 Hz, US model - 100/120/208/230 V, 50/60 Hz
    • Power consumption: 740 VA at 230 V/50 Hz

Mechanical Specification

  • Height: 564 mm (22.2 ") - head in horizontal position
  • Width: 467 mm (18.4 ")
  • Depth: 491 mm (19.3 ")
  • Weight: EU model - 32 kg (70.5 lbs), US model - 36 kg (79.4 lbs)

Thermal

  • Maximum ambient temperature (Ta): 40 °C (104 °F)
  • Maximum surface temperature: 80 °C (176 °F)

Rotating Gobos

  • Glass gobos - outside diameter: 26.8 mm, image diameter: 22 mm, thickness: 1.1 mm, max. thickness = 4 mm, high temperature borofloat or better glass

Control and Programming

  • Protocol: USITT DMX-512
  • Control channels: 11 or 13
  • Bilt-in demo sequences
  • Display: 4-digit LED display
  • Pan/Tilt resolution: 8 or 16bit
  • Master/Slave operation
  • Stand-alone operation
  • Controllable speed of fans
  • Movement control: Tracking and vector
  • Buit-in analyzer for easy fault finding
  • Data in/out: Locking 3-pin XLR

Electromechanical Effects

  • Colour wheel 1: 9 dichroic filters + open
  • Rotating gobo wheel: 6 rotating, indexable, replaceable gobos (1 effect - glass gobo, 3 black and white gobos, 1 multicolor and 1 dichroic gobo) + open
  • Prism: 3-facet prism rotating in both directions at different speeds
  • Dimmer/Shutter: Full range dimming and variable strobe effect
  • Focus: Motorized focus
  • Pan: 530°
  • Tilt: 280°

Rigging

  • Mounting points: 4 pairs of ¼-turn locks
  • 2x Omega brackets with ¼-turn quick locks
