Flexible Input Routing
Convection Cooled
Universal Power Supply
Integrated Life-Safety Features
Up to 8X125W in 1U chassis with no fan
DriveCore™ technology provides >90% efficiency with no compromise in performance
Patented Feedback and Protection Circuits
Amplifier is stable for 2 – 16 Ohm Loads
XFMR 4/8 needed for 70V/100V Applications
| Channels | 4 |
| Sensitivity | 1.4 V |
| Rated Power Output (all channels driven) | 125W per CH @ 4 ohms, 125W per CH @ 8 ohms |
| Signal to Noise Ratio (below rated power 20 Hz to 20 kHz, A-Weighted) | 110 dB |
| THD (full rated power, 20 Hz - 20 kHz) | < 0.05% |
| Intermodulation Distortion (from 0 dB down to -30 dB) | < 0.05% |
| Frequency Response (at 1W, 4/8 ohms) | +/- 0.5 dB |
| Crosstalk (below rated power) 20 Hz to 1 kHz | > 70 dB |
| Common Mode Rejection (20 Hz to 1 kHz) | > 55 dB, typically > 70 dB |
| Voltage Gain | 27 dB |
| DC Offset | +/- 20mV |
| Idle Power Consumption (Standard Mode) | 17.5W |
| Dimensions | 1.75" x 19" x 15.19" |
| Weight | 10lbs/4.54kg |
| Shipping Weight | 15 lbs/6.8 kg |
| IEC Power Connector | 15A |
